Description
The Boss Guitar Pedals always come out on top. This is New is in stock and ready to post out to you, with fast, reliable delivery straight to your door. For more New Guitar Pedals options, read on for full specifications, demos, and secure online ordering.
The latest Boss guitar synthesizer products feature the Serial GK digital interface, a newly-developed connection method that delivers evolved performance over the analogue 13-pin GK interface used in earlier Boss and Roland guitar synth and modelling products. The GKC-AD GK Converter allows you to drive the Serial GK input on the GM-800 Guitar Synthesizer from a Roland GK-3 or GK-3B Divided Pickup, or an instrument equipped with a 13-pin GK output.
Key Features
- Converts analogue 13-pin GK pickup systems to the newly-developed Serial GK digital interface.
- 13-pin GK input and Serial GK output.
- Instrument output for passing normal guitar/bass pickup sounds embedded in the 13-pin connection.
- Compact and rugged metal design.
Specifications
- Nominal Output Level: -10 dBu (GUITAR OUT)
- Recommended Load Impedance: 10 k Ohms or Greater (GUITAR OUT)
- Current Draw: 240 mA
- Power Supply: AC Adaptor (Included)
Connectors
- GK IN Connector: 13 Pins DIN Type
- GK OUT Jack: 1/4-inch TRS Phone Type (for BGK Cable Only)
- GUITAR OUT Jack: 1/4-inch Phone Type
- DC IN Jack
- USB Port: USB Micro-B (Program Update Only)
Weight & Dimensions
- Weight: 340 g / 12 oz
- Dimensions (W x D x H): 115 x 92 x 36 mm / 4.528 x 3.622 x 1.417 inches
Accessories (Included)
- AC Adaptor
- Owner’s Manual
- Leaflet (Using the Unit Safely)
Options (Sold Separately)
- Serial GK Cable: BGK-15, BGK-30
